Essex Flange No Stop (CF1/R)

Essex Flange No Stop (CF1/R).

Compression Fitting

BSP Threaded

Flat & Curved Surfaces

Washers:  EPDM Rubber (Temperatures up to 90° Celsius)

NO-STOP:  Perfect for making easy connection to a tank or cylinder with a dip tube.  The flange is manufactured to allow the connecting pipe to pass into the vessel, thus creating a border mouthpiece which dramatically improves the flow-rate, often used when supplying water to power assisted showers.

This compression flange No Stop is designed to be fitted entirely from the outside of the vessel.  The clever design also means that there is no requirement for a couple and further reduces the time consuming necessity to fit new pipework.

Drill Hole:

15mm Pipe Version - 34mm

22mm Pipe Version - 38mm

28mm Pipe version - 49mm
